- Place of Origin: Changzhou
- Brand Name: PISA
- Model Number: FC850-2400 FC850-4000
Before hot molding sand into the cooling bed, the thermal sensor measure the sand temperature, cooling bed outlet is provided with a humidity probe for the detection of molding sand moisture, according to the data measured to calculate automatically the amount of water added, and then spray water through several groups of nozzles in terms of a certain proportion, guarantee the precision amount of water required by molding sand cooling and humidifying. The first group of nozzles, main control sand moisture, the remaining group control sand temperature.
- Place of Origin: Changzhou
- Brand Name: PISA
- Model Number: FC850-2400 FC850-4000
model | installation power | capacityt/h | blast air volume | Ventilation air volume | Water consumption水 | ||
kw | 120℃~40℃ | 100℃~40℃ | 80℃~40℃ | Nm3/h | Nm3/h | Max.(L/h) | |
FC850-2400 | 5.3 | 14 | 17 | 21 | 3,550 | 4,650 | 650 |
FC850-4000 | 8.8 | 24 | 28 | 35 | 5,900 | 7,750 | 1,000 |
FC1300-3600 | 12.9 | 33 | 38 | 48 | 8,200 | 10,750 | 1,120 |
FC1300-4400 | 12.9 | 41 | 47 | 57 | 10,000 | 13,200 | 1,530 |
FC1750-4000 | 18.2 | 50 | 57 | 72 | 12,250 | 16,100 | 1,650 |
FC1750-4400 | 18.2 | 55 | 63 | 79 | 13,500 | 17,700 | 1,800 |
FC2100-4000 | 20.0 | 60 | 69 | 86 | 14,700 | 19,300 | 2,160 |
FC2100-4800 | 23.5 | 72 | 83 | 103 | 17,600 | 23,100 | 2,520 |
FC2100-5600 | 27.0 | 84 | 97 | 120 | 20,600 | 27,000 | 3,000 |
FC2500-5600 | 37.2 | 100 | 115 | 143 | 24,500 | 32,100 | 3,430 |
FC2500-6400 | 37.2 | 114 | 132 | 163 | 27,900 | 36,600 | 3,860 |
FC2500-7200 | 49.0 | 129 | 148 | 184 | 31,600 | 41,400 | 4,290 |
FC2600-8000 | 52.0 | 143 | 165 | 204 | 35,100 | 46,000 | 4,700 |
FC2500-8800 | 55.5 | 157 | 181 | 225 | 38,500 | 50,500 | 5,150 |
FC2500-9600 | 67.0 | 171 | 198 | 245 | 42,000 | 55,000 | 6,000 |
